Harvester (Model-AG-HR-WQ360Xv)
|
|
|
|
Features
|
|
Combine Harvesting
|
|
- This machine is designed for harvesting and separating grains such as wheat, barley, oats, and legumes from their stalks.The crops can be sown in 2 rows at a maximum distance of 75 cm between rows.
|
| |
| |
|
Key Features
|
|
-
|
Function: Separates the grain from the stalk and converts the stalk into straw, which can then be loaded onto another vehicle.
|
|
-
|
Power Requirements: Requires a tractor with at least 70 horsepower to operate.
|
|
-
|
Harvester Type: Non-traditional (conventional/trailer thresher).
|
|
-
|
Suitable Crops: Wheat, barley, oats, beans, lentils, chickpeas, and other grains (additional sieves and screening systems can be installed for some legumes).
|
|
-
|
Operation: Harvests the grain and separates it from the stalk. Converts the stalks into straw and unloads them onto another transport vehicle. Stores the grain in a dedicated storage compartment and then simultaneously unloads it onto another conveyor.
|
|
-
|
Mechanism of Operation: The harvested ears are mixed between the drum and counter-drum, and the seeds are drawn out and separated from the husk and stalk. Power Required: Operated by the tractor's power take-off (PTO) and requires a minimum tractor power of 70 hp (70 mechanical horsepower).
|
|
-
|
Maneuverability: Highly maneuverable and operates efficiently even in small fields.
|
|
Technical Specifications
|
|
Feature
|
Unit
|
Value
|
|
Length
|
cm
|
660
|
|
Weight
|
cm
|
260
|
|
Height
|
cm
|
260
|
|
Weight
|
kg
|
3250
|
|
Number of Hammers (Bater Finger Units)
|
units
|
54
|
|
Bater Width
|
cm
|
1200
|
|
Harvesting Width
|
cm
|
200
|
|
Harvesting Height
|
cm
|
8-10
|
|
Storage Capacity (Tank)
|
kg
|
700
|
|
PTO Rotation Speed
|
rpm
|
540
|
|
Tire Size
|
|
10/75-15.3
|
|
Working Capacity
|
kg/hr
|
500-1500
|
| |
|
|
|
