Agricultural Pesticide Sprayer (Model-AG-PS-NSton15050H)

Features

introduction

-        The 600Lt, 800Lt, 1000Lt and 2000Lt Trailed airblast are compact in design. All tanks (main tank, hand washing tank and circuit washing tank) are designed and placed to avoid to damage branches and buds. Standard Equipment includes hand wash tank, usable in case of emergency when the operator accidentally comes into contact with chemicals. The circuit washing tank (mandatory for professional use) allows the complete rinsing of the entire spraying system. Configurable according to your needs and type of crops, choosing between the fans and the various options and accessories available.

-        System washing tank, hand washing tank, external level, suction filter with valve, mixer in tank, remote control. Hot galvanized fan unit, stainless steel nozzle holder rods, nylon glass fan with adjustable blades, 1-speed gearbox with disengagement, adjustable axle, brass single nozzle bodies with anti-drip with check valve and ceramic nozzles 1.5-1.2 mm.

-        This range of towed sprayers is designed for use in vineyards, orchards, gardens, and greenhouses. It features a design that combines high performance with a compact size to save time during operation.

Key Specifications and Features:

-

Capacity: Available with polyethylene tanks in various capacities including 600, 800, 1000, 1500, 2000, and 3000 liters.

-

Chassis: Constructed with a low frame made of hot-dip galvanized steel sections for durability.

-

Fan Unit: Includes a galvanized fan unit, stainless steel rods with nozzle bodies, and a nylon and glass fan with adjustable blades.

-

Standard Equipment: Comes equipped with a system flush tank, a hand flush tank, an external level indicator, an intake filter with a valve, a drain valve, and an in-tank mixer.

-

Control: Equipped with a BY MATIC remote control.

Operational Benefits

-

Driver Protection: The design minimizes the driver's exposure to plant protection products. Cleanliness: The fan unit prevents leaf and debris from being sucked up from the ground.

-

Precision: The technology used helps contain drift and ensures the spray reaches the target accurately.

Specification

Tank and Frame

Tank Capacity:

Available in multiple options ranging from 600, 800, 1000, 1500, 2000, up to 3000 liters.

Material:

High-density polyethylene tank.

Frame:

Low-profile frame designed for easy maneuverability, made of hot-dip galvanized steel for corrosion resistance.

Additional Tanks:

Equipped with an integrated system flush tank and a separate handwash tank.

Fan Unit (Blower)

Fan:

Made of nylon and glass with adjustable blades for airflow control.

Gearbox:

Single-speed transmission wih disengagement.

Air Guide:

Galvanized fan unit with stainless steel rails.

Spray System and Control

Nozzles:

Dual brass nozzle heads with anti-drip technology and shut-off valves. Control Unit: A "BY MATIC" remote control is installed for easy driver access.

Filtration:

A suction filter with a valve allows for easy cleaning and maintenance.

Additional Features

Mixing:

A hydraulic mixing system inside the tank ensures the homogeneity of the pesticides.

Level Indicator:

A clearly visible external indicator monitors the remaining liquid level.

Applications:

Specifically designed for vineyards, orchards, greenhouses, and green spaces.
