Product Details

Thresher Machine (Model-AG-TM-Vat235A+1)

Features

Wheat Thresher (multi-purpose harvester)

he multi-purpose thresher can harvest wheat, rye, barley, peas, sorghum, millet, lentils, sesame, figs, broad beans, cumin, and other crops. The necessary motion for these operations is transmitted via a rear metal shaft. Another advantage of our machines is the ability to load the harvested grain or legumes into bags or trailers using the integrated bagging system.

Feature:

Unleashed Harvesting Power

-

This top-quality thresher is the farmer's best helper, combining traditional blending methods with modern technology. Powered by the tractor's rear axle, this machine eliminates the problem of fuel consumption via belts, improving performance and reducing fuel consumption in the field.

Continuous Harvesting Performance Thanks to the Power of the Tractor's Rear Axle

-

It draws its power directly from the tractor's rear axle (PTO) via the shaft. This system completely eliminates the power loss and slippage problems associated with traditional belt systems. Thanks to modern technology, the torque generated by the tractor is transferred to the thresher without any loss. The result: higher productivity with lower diesel consumption.

-

The integrated airbag system, the most prominent feature of this machine, reduces labor costs. Thanks to the powerful airflow, the blended product is loaded directly into the bag or trailer. This reduces the need for labor and speeds up the harvesting process.

Versatile Harvesting: Chickpea and Wheat Harvester

-

This machine is more than just a wheat harvester; it's a versatile "harvesting plant." Thanks to its standard equipment, it achieves an ideal harvest for wheat, barley, oats, and rye. However,

-

With a simple replacement of the pulley, belt, and sieve, your machine transforms into a professional-grade machine for processing fine legume products such as chickpeas, lentils, beans, figs, and cumin. Precise distribution settings, which break down the product without crushing or wasting grains, preserve the quality of your harvest.

Impact-Resistant Steel Structure and Long Service Life

-

We understand the harsh conditions in the field. That's why our vertical bag mixer is designed with a reinforced steel structure to resist impacts and vibrations. Its robust frame, weighing 1450 kg, minimizes vibration during operation. Forty-four specially hardened compactors transform even the toughest stalks into straw in seconds, while separating the grains with exceptional precision.

Specification

Dimensions and Weights

Overall Length:

3850 mm

Overall Width:

2000 mm

Overall Height:

2300 mm

Total Weight:

1450 kg

Tire Size:

600 x 16

Machine Performance and Components

Thresher Width:

1200 mm

Number of Threshers:

44

Thresher Speed:

1200 rpm

Tapping System:

Helizon Auger

Production Capacity:

2200 kg/hr

Operating Requirements (Tractor)

Required Tractor Power:

20 hp to 100 hp

PTO Speed:

540 rpm
