Product Details

Pumps (Model-AG- Pmp/Sol/1320Pxi32)

Features

§  a 6-inch AC borewell solar pump set designed for reliable water pumping in agricultural and rural applications

§  It operates using AC induction motor technology and is compatible with solar power as well as grid supply, ensuring uninterrupted operation under varying power conditions.

Key Specifications and Features:

Operational Specifications (Model Range)

‒

H.P Range: 3.0 to 25.0 HP, making it suitable for medium and large depth wells.

‒

Head Range: Capable of raising water to heights ranging from 20 to 300 metres.

‒

Flow Range: Provides water quantities ranging from 8.1 to 70.0 cubic meters per hour.

Smart technologies and control

‒

Smart Hybrid Technology: It allows the pump to operate with a dual power source, allowing switching between solar energy and regular electricity (AC) to ensure continuity of operation.

‒

99.8% MPPT Efficiency: Equipped with a maximum power point tracking system to ensure maximum power is extracted from the solar panels even in low light conditions.

‒

Remote Monitoring System (4G RMS): Supports remote monitoring and control of the pump via 4G networks, making it easier to track performance and diagnose faults.

‒

Automatic and Manual Adjustment Function: Provides operational flexibility to adjust parameters based on well need.

Design and components

‒

AC Induction Motor: It is based on induction technology, which is known for its long lifespan and low maintenance compared to high-capacity DC motors.

‒

Robust Construction: Pumps are made of corrosion and rust-resistant materials (often stainless steel or treated cast iron) to withstand heavy underground work.

‒

6" Size: Specifically designed to fit large diameter tube wells (Borewell).

All uses

Agricultural sector (main use)

‒

Irrigation of large farms: Irrigation of crops and fields that require large amounts of water and a continuous flow (up to 70 m3/hour).

‒

Modern irrigation systems: Operating drip irrigation and sprinkler irrigation systems that require a certain pressure for the heads and sprinklers to work efficiently.

‒

Watering livestock: Providing continuous water sources for livestock and poultry farms in remote areas.

Community and civilian water supply

‒

Feeding villages and residential communities: raising water from deep wells (up to 300 meters) and storing it in overhead tanks for distribution to homes in areas suffering from electricity outages.

‒

Government projects: used in initiatives to provide clean drinking water in rural areas.

Industrial and commercial uses

‒

Factories and construction sites: Providing the water needed for manufacturing or construction operations in sites that are not connected to the national electricity network.

‒

Resorts and playgrounds: Irrigating green spaces and extensive gardens in hotels, tourist resorts and golf courses using clean energy.

Hybrid applications (Dual Power)

‒

Continuous work: Thanks to Smart Hybrid technology, it can be used in projects that require pumping water day and night; It runs on solar energy during the day and automatically switches to electricity or generators at night.

Water resources management

‒

Reducing the groundwater level: It is used in engineering projects that require withdrawing water to relieve hydraulic pressure in certain locations.

Specification

solar Power

3200Wp

Rated Voltage

220V

Rated Current

9.5Amps

Rated Head

30m

Flow Rate

105000 Liter Per Day

Outlet In inch

2"

Motor Type

Water Filled

Head Range:

20 – 300 meters

Flow Range:

8.1 – 70.0 m³/hr

MPPT Efficiency:

Up to 99.8%

Dual Power Hybrid:

Solar + Grid compatible

Auto/Manual Tuning:

Allows controller tuning based on conditions

Motor Voltage

3-Phase, 380-440 VAC

Frequency

50 Hz

Max Solar Input Voltage

~550 VDC

Max Solar Power

From ~3 kW to ~25 kW (depending on HP)

Controller Efficiency

≥97%

Protection

Dry run, over/under voltage, short circuit

Operating Temp

-10 °C to +60 °C
