Product Details

Thresher Machine (Model-AG-TM-RRT1-50u)

Features

Bean Thresher

This is a self-propelled agricultural machine. Specifically designed for grain threshing, it is primarily used for threshing beans and similar crops. Its self-propelled mobility is achieved through a track-based drive system. This machine is ideal for small and medium-sized farms that grow legumes and are looking to increase harvest speed and reduce manual labor.

Feature and Performance:

-

Drive System:

The machine uses rubber tracks, allowing it to operate efficiently on muddy or uneven terrain without the need for digging.

-

Transmission:

Equipped with a transmission that allows switching between 3 different speeds to suit working conditions.

-

Performance:

Offers a working efficiency of 300-400 kg/hr.

-

Engine:

Powered by a gasoline engine (shown in red in the image) that provides the necessary power for threshing and self-propelled movement.

-

Engine Power:

Maximum engine power: 6 kW / 8 hp.

-

Working Mechanism (Threshing):

.

Primary Function: Specially designed to separate beans from pods and shells.

.

Applications: Primarily used for threshing various types of beans, including broad beans and red beans.

.

Drive System: Design: Features a compact structure for easy transport and storage, with separate outlets for cleaned beans and shells. Efficiency: It is classified as a "self-propelled" machine, meaning it does not need a tractor to pull it, but is driven manually by the operator from behind.

Specification

Dimensions (L x W x H)

2,630 mm x 910 mm x 1,660 mm

Driving Type

Self-propelled, crawler/track-driven

Transmission

3 forward speeds, 1 reverse speed

Engine

Gasoline, 6 kW (8 HP) max output

Working Capacity

Approx. 300 - 400 kg per hour

Primary Crops

Broad beans, kidney beans, and similar pulse crops
