Harvester (Model-AG-HR-PR555D)

Features

Potato Harvesting

A three-point hitched medium-size potato harvester is a machine specifically designed for harvesting potatoes from a field. It is equipped with a three-point linkage system, which allows it to be easily connected to a tractor and pulled through the field. It is typically used on medium to large-sized fields with relatively flat terrain and is capable of working in two rows at a time, with a single pass through the field covering two ridges, quickly and easily harvesting crops with minimal labor and cost. Some models of the medium-size potato harvester may also include additional features such as automatic grading and sorting capabilities, and the ability to remove weeds and other unwanted plants during the harvesting process.

Working process:

The medium-size potato harvester with a three-point linkage consists of a series of conveyor belts, brushes, and other mechanical components that work together to efficiently dig up and collect the potatoes. The potatoes are first loosened from the ground by a series of digging tines or plows, and then lifted onto the conveyor belts where they are carried to the rear of the harvester and leave on the ground for collecting. From there, the potatoes are sorted and separated from the dirt and debris by a series of brushes and other cleaning mechanisms, and then dropped onto ground for collection.

Medium-Size Potato Harvester Advantages

-

Efficient operation: Medium-size potato harvesters are designed to be highly efficient, with a series of mechanical components that work together to efficiently dig up and collect the potatoes. This can result in faster harvesting times and higher yields.

-

Easy to use: Medium-size potato harvesters with a three-point linkage system are typically easy to operate and maintain, making them a good choice for farmers who do not have a lot of experience with larger, more complex harvesting equipment.

-

Cost-effective: Medium-size potato harvesters with a three-point linkage system are generally less expensive to purchase and operate than larger harvesters, making them a cost-effective option for medium to large-sized farms.

-

Greater stability: Because the three-point linkage harvester is mounted on the tractor, it has a more stable and secure connection to the tractor, which can be especially beneficial in rough or uneven terrain.

-

Versatility: Medium-size potato harvesters with a three-point linkage system are capable of working in a variety of different row and ridge configurations, making them suitable for use in a range of different field conditions.

Technical Specifications

Size(mm)

4046*2090*1300

Weight(kg)

1580

Working Rows

2 ridges 2 rows

Working Width(mm)

1650

Applicable ridge width(mm)

≤700

Digging depth(mm)

150～300

Productivity(hm2/h)

0.32-0.55

Digging blade form

Combined shovel blade

Conveying (separation) device

Serrated belt grid type

Linkage

Three point-linkage

Matched power(kw)

89.4~119.3

Matched power(hp)

120~160

Digging blade form

Combined shovel blade
