Automatic hot water maker
|
|
|
|
Blancher in stainless steel Mod. 15 for production up to 1 5 quintals / hour.
|
|
The machine is for cooking a continuous cycle of a wide range of products. Constructed entirely in AISI 304 stainless steel, it will consist of:
|
|
-
|
drum product container, with internal spiral for advancement, pitch 250 mm.
|
|
-
|
one-piece top cover that can be opened with a hinge on the longer side by means of a pneumatic cylinder,
|
|
-
|
direct steam heating with steam-water mixing injector and manual adjustment valve,
|
|
-
|
indirect heating by coil with pneumatic thermoregulating valve, 3 shut-off valves, Y-filter, condensate drain, with relative bypass.
|
|
-
|
motorization of the drum by means of speed variator for adjusting the residence time of the product from 2 to 10 min.
|
|
-
|
stainless steel product loading hopper
|
|
-
|
product discharge hopper in stainless steel
|
|
-
|
lateral service gangway
|
|
Technical data
|
|
-
|
Overall dimensions length 2500 mm. width 1500 mm.
|
|
-
|
Cylinder diameter 700 mm.
|
|
-
|
Cylinder length 2000 mm.
Installed electrical power: 3 Kw
|
|
-
|
Max . Steam consumption : 100 Kg / h. at 4
|
|
-
|
Ate Water consumption: 5 lt / m '.
|
|
-
|
Production: up to 10 ql / hour depending on the type of product
The machine is also equipped with:
|
|
|
Instrumentation with electronic temperature controller for temperature control
|
|
|
Electropneumatic system complying with IP65 standard with stainless steel frame and low voltage auxiliary controls
|
|
|
Accident prevention protections according to CE regulations
|
|
|
Equipment and maintenance manual
|
| |
|
|
