LINEAR AUTOMATIC FRYER -CONTINUE- Model FRC200
|
|
|
|
Completely made in Aisi 304 stainless steel Heating by external heat exchanger.
|
|
Complete of:
|
|
-
|
series of reels and first stainless steel belt with crosspieces for product advancement and speed motor variator
|
|
-
|
second slanted stainless steel belt for product evacuation; complete with speed variator
|
|
-
|
oil piping, distribution and circulation complete with by-pass
|
|
-
|
fume collection hood with condensation drainage duct and telescopic fume exhaust pipe diam. 350 mm.
|
|
-
|
hydraulic device for hood and belt lifting
|
|
-
|
insulation with stainless steel lining of the tank Dimensions:
|
| |
Total length: mm. 6350 =
|
|
|
Immersed length: mm. 4900 =
|
|
|
Belt width: mm. 600 =
|
|
|
Total width: mm. 1250
|
|
|
Installed power: 15 KW. Complete of:
|
|
|
HEATING VEGETAL OIL GROUP WITH DIATHERMIC OIL SYSTEM.
|
|
|
Consisting of:
|
|
|
heat exchanger with straight tube bundle with fixed plates having all the parts in contact with the vegetable oil in stainless steel Aisi 304
|
|
|
complete piping of valves and dilators for diathermic oil circulation
|
|
|
vegetable oil temperature control instrumentation
|
|
|
ASTM 304 stainless steel vegetable oil transfer pump, flow rate 10 m3 /h.
|
|
|
vegetable oil filtering tank with tape
|
| |
|
|
|
