Agricultural Pesticide Sprayer (Model-AG-PS-PU500-11S)
|
|
|
|
Features
|
|
introduction
|
|
- The sprayer is an advanced device designed for easy pump and multiplier maintenance. Its design allows for early turning and reduced operating time thanks to the early disconnection of the tractor's power drive shaft, which also minimizes leaf and debris ingress. The impeller can be set in 6 seconds, and the sprayer features symmetrical distribution, ground dispersers, and electric and manual overhead dispersers. It also includes anti-drift nozzles and an improved mixing system without a tube or drive shaft running through the tank. The sprayer is suitable for farms with row spacing of 5 meters or more. At only 115 cm high and with a low center of gravity, it offers greater stability on sloping ground, and the rounded rear of the tank allows for a lower steering angle. There is no risk of damage to the front impeller during turning. Optional features include an F2 suction probe for dosing powdered and granular pesticides and a highly polarized TIFONE (E±S+) electrostatic charging system.
|
|
Features:
|
|
-
|
Machine Type: Axial Fan Pesticide Sprayer
|
|
-
|
Applications: Designed specifically for use in vineyards and orchards
|
|
-
|
Front Side Fan: Maximum spraying capacity. Emission towards the rear. No fog to the tractor.
|
|
-
|
Fan and Pump integrated: Minimized the Pressur Loss Maximum Efficiency.
|
|
-
|
Propeller Volume of Air Adjustable instantly: Save up to 50% of pesticide.
|
|
-
|
Advanced device: easy pump and multiplier maintenance, earlier turning and limited work time thanks to earlier disengagement of the tractor PTO, less intake of leaves and debris from the terrain.
|
|
-
|
Propeller Adjustable in 6 sec.
|
|
-
|
Symmetric Distribution, Right-Left.
|
|
-
|
Floor Deflectors.
|
|
-
|
Top Electrical and Manual Deflectors.
|
|
-
|
Anti-drift Nozzles.
|
|
-
|
No tube nor driver shaft through the tank: Improved mixing.
|
|
-
|
Suitable for Plantations with row spacing up to 5 m and up to 5 m high. and more.
|
|
-
|
Only 115 cm tall with Low centre of gravity: increased stability also on sloping ground.
|
|
-
|
Back of tank nicely rounded = reduced steering angle.
|
|
-
|
No risk of damage to the fan during turning because it is at the front.
|
|
-
|
Sucking PROBE F2 for pesticide dosage in Powder and Granular
|
|
-
|
Components of this Type of Sprayer:
|
|
.
|
Tank: For storing pesticides or other sprayable materials.
|
|
.
|
Pump: For drawing and pumping liquids at high pressure.
|
|
.
|
Turbo Fan: For providing the compressed air necessary for spray distribution.
|
|
.
|
Filters: To purify liquids and protect pipes from blockages.
|
|
Specification
|
|
-
|
Equipped with a 32 AA Turbo Front fan that operates symmetrically on both the left and right sides.
|
|
-
|
Features anti-drift nozzles to ensure spraying accuracy.
|
|
-
|
The design includes a high-density polyethylene (HD) tank with a low center of gravity for increased stability on sloping terrain.
|
|
-
|
Suitable for farms with row spacing up to 5 meters and a height of up to 5 meters.
|
|
-
|
The control system can be either electric or manual.
|
|
Characteristics
|
|
Mobility
|
towed
|
|
Application
|
for viticulture, for arboriculture
|
|
Type
|
with axial propeller
|
|
Technology
|
hydraulic
|
|
Control regulator
|
electric, manual
|
|
Other characteristics
|
with diaphragm pump, air-assisted, electrostatic, misting, tracked
|
|
Capacity
|
1,000 l (264.2 gal)
|
|
Pump pressure
|
40 bar (580.2 psi)
|
|
Air flow
|
62,000 m³/h (2,189,509.3 ft³/h)
|
| |
|
|
|
