Harvester (Model-AG-HR-NY50ig)
|
|
|
|
Features
|
|
- Harvest crops as close to the ground as possible with the modern cutting blade.
|
|
- Minimize grain loss thanks to the dual-speed central feed section.
|
|
- Enjoy faster harvesting without compromising cut quality thanks to the dual-drive double cutting blade and 10.2 cm wide vertical drive motor.
|
|
- Achieve more by eliminating the need for combine head calibration.
|
|
Overview:
|
|
-
|
Increase grain capacity in the hopper with the dual-speed central feed section. The low-speed setting reduces the impact of the harvester fingers and drum blades when handling the crop. This ensures that easily hulled crops like lentils and soybeans don't spill from the feeder. Use the high-speed setting for canola or high-yield grains to prevent slug feeding and ensure the drum doesn't clog.
|
|
Advantages:
|
|
-
|
Minimize downtime during harvesting due to combine head blockage, allowing for longer harvests at higher productivity levels.
|
|
-
|
The high torque of the feed cylinder is matched to the combine's power to ensure optimal feed rates. The high torque of the front feed cylinder enables operators to confidently harvest hard forage crops like canola.
|
|
-
|
Additionally, the central crop flow separator prevents underfeeding of soft crops. When the crop is not harvested across the entire screen width, the central crop flow separator prevents it from overrunning the central feed section and moving to the opposite curtain belt.
|
|
Key Features
|
|
-
|
Cutting System: The flexible cutting bar allows the cutting bar to follow uneven terrain, cutting the crop as close to ground level as possible and minimizing waste.
|
|
-
|
Two-Speed Central Feeding Section: The speed of the central feeding section can be adjusted for canola and other crops; for example, a slower speed for easy-hulling legumes or a higher speed for canola and other crops.
|
|
-
|
Optional Screw Layers: An optional 18-inch (45.7 cm) diameter screw (perforated) shell is required to help transfer crops, especially canola, to the layers.
|
|
-
|
Dual-Action Knife: Features a dual-action knife cutting system and a dual-crossing system, enabling higher speeds without compromising cut quality. Draper Secretarial Badges: Precision-machined and centered badges, with a 101.2 cm (39.8 in) increase in notification speed and material flow.
|
|
Technical Specifications
|
|
Feature
|
Specifications
|
|
Cutting Width:
|
12.19 meters (40 feet)
|
|
Frame Type:
|
Rigid frame with flexible cutterbar
|
|
Cutterbar Flex:
|
Up to 190 mm (7.5 in) vertical on full width
|
|
Knife Drive System:
|
Double-cut, dual drive, shaft-driven
|
|
Knife Speed:
|
520 rpm (X series); 490 rpm (S series)
|
|
Side Belt Width:
|
101.6 cm (40 in)
|
|
Center Belt Width:
|
177.8 cm (70 in)
|
|
Belt Speed Control:
|
speed control from the cab (side belts only)
|
|
Feed Drum Diameter:
|
414 mm (16.3 in)
|
|
Feed Drum Speed:
|
Low: 200 rpm; High: 240 rpm
|
|
Top Auger:
|
Optional (hydraulic drive, 45.7 cm / 18 in diameter)
|
|
Approximate Weight:
|
4125 kg (9095 lb)
|
|
Transport Dimensions:
|
Transport width in field mode: 13.1 m (43 ft)
|
| |
|
|
