Product Details

Planter Machine (Model-AG-PL-AutPP1500Sr)

Features

Automatic Potato Planter

-        The machine is characterized by its ability to operate efficiently in various conditions, whether in light or heavy soil. Its operating mechanism relies on a vertical conveying system, where potato tubers move within cavities between two rollers, supported by two upward-moving rubber belts.

-        When the tubers reach the top, the mechanism turns to begin the downward movement, precisely dropping the potatoes into the prepared holes in the soil. The tubers are fed from the hopper and lifted by scoops mounted on a continuous rubber belt that moves vertically between the two rollers.

-        As the scoops turn downwards from the top, they continue to empty the tubers, which then fall to the soil surface at the bottom turning point. Afterward, the rear covering discs cover the potato tubers, ensuring they are properly buried.

Main features and uses:

-

Precision planting: The machine ensures extremely precise seed placement, improving plant growth and increasing yield. It also guarantees uniform row spacing and depth to ensure each plant receives adequate nutrition.

-

Time and Labor Efficiency: Automation reduces reliance on intensive manual labor, significantly saving time and effort and increasing efficiency.

-

Efficient Operation:

.

Potato tubers are loaded into an overhead hopper.

.

A mechanical or pneumatic metering system transfers the tubers to seed drop tubes at regular intervals.

.

A furrow opener creates a groove in the soil, into which the tubers are dropped.

.

A covering device then fills the grooves with soil over the planted seeds.

-

Versatility: Planting spacing and depth can be adjusted to suit different soil conditions and crop requirements.

-

Durable Construction: Often constructed from robust materials such as cast iron or mild steel to withstand harsh field conditions and ensure a long service life.

-

Operational Flexibility: Works with tractors (requires a certain horsepower) and features a low-maintenance design.

Specification

Specifications

Units

AutPP1500Sr-2

AutPP1500Sr-2S

AutPP1500Sr-4

Type

---

Belt

Chain

Belt

Working Depth

mm

10-20

10-20

10-20

Number of Tines

3

3

6

Length

cm

180

190

315

Width

cm

170

170

170

Height

cm

180

140

180

Weight

kg

460

560

710

Required Power

hp

45-70

45-70

45-70
