Harvester (Model-AG-HR-i9500)
|
|
|
|
Features
|
|
Self-Propelled forage harvester
|
|
This machine is the most efficient green fodder harvester developed by our company. Primarily used for harvesting corn straw silage and yellow grain (without husks), it can perform various operations such as cutting, conveying, crushing, chopping, throwing, loading, and more.
|
|
Product Information:
|
|
-
|
Function: Used for harvesting forage crops such as corn, alfalfa, and sorghum stalks for silage or green fodder for animals.
|
|
-
|
Features:
|
|
.
|
Self-Propelled: Powered by its own diesel engine (175 hp or 320 hp models available).
|
|
.
|
Multi-Task: Can perform cutting, conveying, crushing, and shredding tasks in a single operation.
|
|
.
|
Flexible Harvesting: Features a compact structure and small turning radius, making it suitable for working in small fields or hilly and mountainous areas.
|
|
.
|
Feeding Mechanism: Employs vertical drum feeders that allow harvesting regardless of row spacing.
|
|
.
|
Efficient Design: Features high operating efficiency and reliability, with a side discharge system.
|
|
Specification
|
|
Machine Type:
|
Reaper Harvester
|
|
Application:
|
Corn, Wheat
|
|
Driven Type:
|
Hydraulic drive
|
|
Warranty:
|
1 Year
|
|
Core Component:
|
Gearbox, Bearing, Engine
|
|
Usage:
|
Corn Harvester, Other
|
|
Type:
|
Combine Harvester
|
|
Machinery Test Report:
|
Provided
|
|
Working Width(mm):
|
3000 mm
|
|
Tractor Power(hp):
|
0 – 360 HP
|
|
Row Distance(mm):
|
10 – 3000 mm
|
|
Dimension:
|
7300*3030*5100
|
|
Weight:
|
9740 KG
|
|
Rated Power of Supporting Engine:
|
265kw
|
|
Rated Speed of Supporting Engine:
|
2200
|
|
Cutting width (mm)
|
3000
|
|
Guiding Wheel Track:
|
1980
|
|
Drive Wheel Track:
|
2280
|
|
Wheelbase:
|
2500
|
|
Productivity:
|
60t/h
|
| |
|
|
|
