Hay Baler (Model-AG-HB-ZWO422ix)
|
|
|
|
Features
|
|
Round Baler
|
|
- Round baler designed for harvesting and compacting forage crops such as hay, straw, or silage into cylindrical bales. This type of baler uses a variable chamber that allows bale diameter to be adjusted during operation, enabling flexibility in bale size depending on crop and storage needs.
|
|
- The baler is powered via the tractor’s PTO (Power Take-Off) and includes a wide pickup system that lifts crop material from the swath and feeds it into a bale forming chamber. Inside the chamber, belts, rollers, or a combination of both rotate to form the forage into a dense round bale. An automatic net or twine wrapping system secures the bale before it is discharged from the rear of the machine.
|
|
Key Features:
|
|
-
|
ROTO CUT (RC) Cutting System: Equipped with 14 knives, this system ensures precise cutting of forage up to 70 mm in length, increasing bale density and facilitating subsequent forage distribution.
|
|
-
|
Robust Construction and Robust Baling Chamber: Utilizing a system of reinforced steel rollers, this system provides even pressure to produce bales with a standard diameter of 1.3 m and a width of 1.2 m.
|
|
-
|
Automatic Lubrication System: Features automatic chain lubrication, reducing maintenance time and extending machine lifespan.
|
|
-
|
Intelligent Control: Operated via either the OPERATOR or COMMUNICATOR II system, this system gives the operator complete control over the baling process from inside the cab.
|
|
-
|
Pick-up: Featuring a wide pickup width, typically up to 2.1 m, this system allows for the collection of large quantities of crops, even on challenging curves.
|
|
Specification
|
|
Demand for power take-off. min.
|
115 kW
|
|
Bale-Ø from-to
|
1.25-1.35 m
|
|
Bale width from-to
|
1.2 m
|
|
Standard tyres
|
11.5/80-15.3
|
|
Pick-up width
|
2.1 m
|
|
Weight
|
3 t
|
|
Number of axles
|
1
|
|
Transport length
|
4.71 m
|
|
Transport width
|
2.57 m
|
|
Transport height
|
2.57 m
|
|
Control unit
|
1/1 ew/dw
|
|
hydraulic supply
|
F
|
| |
|
|
