Product Details

Trailers (Model-AG- TRI32801/v100)

Features

§  The interchangeable chassis allows for easy swapping of containers or pallets, making it suitable for year-round use (harvesting, transporting equipment, and transporting fertilizers). Hydraulic suspension provides exceptional stability and comfort at speeds up to 50 km/h.

§  This trailer also boasts a powerful dumping system and technical features, including a rear dumping angle of up to 51 degrees and a required oil volume of 16 liters at 210 bar pressure.

§  The trailer is constructed with high-strength Hardox 450 steel (3.2 mm thick for the floor and 2 mm for the sides) to ensure durability while maintaining a lightweight design.

Key Specifications and Features:

This trailer offers a range of advanced engineering solutions that make it one of the most efficient and versatile agricultural trailers available, Here are its key technical and operational features:

‒

Suspension and Control System (MetaQ)

§  Hydraulic Suspension: Utilizing "communicating vessels" technology, it provides a wide track and exceptional stability, even on rough terrain, ensuring a smooth and safe ride.

§  Axles and Maneuverability: Equipped with robust BPW axles, it offers the option to add a rear (or front) steering axle for improved maneuverability and reduced tire wear, along with a hydraulic locking feature when reversing.

§  Laser Alignment: The axles are laser-aligned to minimize rolling resistance, resulting in approximately 25% fuel savings and extended tire life.

‒

Design and Chassis

§  Versatility (MetaQ System): The chassis allows for easy container or flatbed changes, enabling the same chassis to be used for various purposes (grain, silage, machinery transport) throughout the year.

§  Weight and Durability: The company uses high-strength Brinell steel, which reduces the trailer's curb weight and increases its ability to carry heavy loads.

§  Corrosion Protection: Metal parts are coated using the KTL (Catophoretic Deposition) method to ensure maximum protection against rust.

‒

Performance and Capacity

§  Load Capacity: Some models have a loading capacity of up to 52 cubic meters and are designed for the efficient transport of grain, silage, and solid manure.

§  Speed ​​and Safety: The axles are designed to withstand speeds up to 62 km/h and feature an advanced hydraulic (or pneumatic) braking system to ensure safe stopping of heavy loads.

Specification

Weights and Capacities

Gross Weight )Technical Load(:

14,000 kg.

Payload:

10,000 kg.

Container Capacity:

The standard capacity of the container shown is approximately 17.5 m³.

Dimensions and Structure

Container Length:

4,165 mm.

Container Width (Internal):

2,400 mm (ideal for transporting bales and pallets).

Overall Width:

2,550 mm

Side Height:

1,750 mm in the Eucon model.

Material:

3 mm thick floor and 2 mm thick sides, made of Brinell 450 steel (known for its high strength) to ensure a longer lifespan and lower weight.

Axle and Suspension System

Axles:

Two high-quality BPW tandem axles. Suspension System: Boggi suspension with a center distance of 1,050 mm.

Load Capacity:

Designed to support 6 tons per axle.

Chassis Protection:

The chassis is treated with KTL (electroplating) coating for maximum rust and corrosion resistance.

Hydraulic System and Brakes

Tipping Cylinder:

Front-mounted for better balance and increased mechanical strength during unloading

Brakes:

Effective hydraulic braking system suitable for heavy loads.

Additional Options

Rear Door:

Wide-opening hydraulic tailgate ensures smooth material unloading.

Tires:

Standard 500/50x17 tires with multiple options for wider tires to reduce soil compaction.
