Product Details

Trailers (Model-AG- TRI32990-v650)

Features

This trailer is the latest in high-capacity transport solutions, specifically designed for demanding agricultural, construction, and industrial applications. With its robust steel frame, three-axle design, and advanced towing system, it's built to handle the heaviest loads efficiently and reliably. Engineered with the latest agricultural and construction technologies, it combines durability, safety, and versatility, making it a reliable choice for professionals who need dependable bulk material transport.

Key Features:

‒

Triple Axle Strength:

Three axles with oversized tires provide superior stability and optimal load distribution.

‒

Heavy-Duty Construction:

Reinforced steel panels and frame ensure long-lasting durability in harsh conditions.

‒

Large Loading Capacity:

A spacious rectangular cargo box designed for bulk materials such as grain, silage, gravel, or building materials.

‒

Easy Access:

Integrated ladder for easy and safe access to the trailer box.

‒

Advanced Towing System:

Front hitch compatible with tractors and heavy-duty towing vehicles.

‒

Corrosion Resistance:

Powder coating protects against rust and weather damage.

‒

Applications

•

Agriculture: Transporting grain, silage, and harvested crops.

•

Construction: Transporting sand, gravel, and heavy raw materials

•

Industrial Use: Efficient transport of bulk materials in manufacturing and logistics.

‒

Advantages:

•

Efficiency: Large capacity reduces the number of trips, saving time and fuel.

•

Durability: Designed to withstand rough terrain and heavy use.

•

Versatility: Suitable for agricultural and industrial applications.

•

Safety: Three-axle design ensures stability and safe traction

Specification

Overall Length

10.0 - 12.0 m

Overall Width

2.5 – 2.8 m

Overall Heigh

3.5 – 4.2 m

Load Volume:

35 - 50 m³

Load Capacity:

18,000 - 24,000 kg

Unladen Weight:

6,000 - 7,500 kg

Axle System:

Three-axle

Number of Tires:

6 (Large, Agricultural)

Wheel Size:

22.5” in

Ground Clearance

400 – 500 mm

Hitch Height:

450 – 500 mm

Braking System

Hydraulic or Pneumatic Brakes

Material Thickness

5 - 7 mm, Reinforced Steel

Maximum Traction Speed:

40 km/h (in the field), 60 km/h (on the road)

Body Coating:

Powder-coated Corrosion-resistant
