Product Details

Hay Baler (Model-AG-HB-99501CC120-5)

Features

Variable Chamber Baler

-        We present to you this machine equipped with the latest technologies and pioneering innovations that have revolutionized the way variable chamber balers operate. This baler, equipped with a drum belt, ensures a bountiful harvest. The latest generation is expected to redefine the circular baling process with its advanced drum belt technology, which improves capacity by up to 20% and density by up to 5%. Furthermore, farmers can choose a maximum bale size of 150 cm or 180 cm to suit their individual needs. The drum belt baler will also attract attention with its distinctive, streamlined lines, adding a touch of elegance to every bale operation.

-        This advanced variable chamber circular baler is designed to deliver high performance in diverse harvesting conditions. This model is capable of producing bales with a diameter of up to 1.8 meters, with improvements in capacity of up to 20% and density of up to 5% compared to previous generations.

Features:

Basic Technical Specifications

‒

Bale Dimensions: Variable diameter between 90 and 180 cm, with a fixed width of 120 cm.

‒

Tractor Requirements: Requires a minimum power take-off (PTO) of 105 hp (approximately 78 kW).

‒

Feeding System: Utilizes a pickup unit with a working width of up to 2.3 meters to ensure efficient hay collection.

‒

Chamber Construction: Employs Roll-Belt technology, combining forming rollers and four 273 mm wide endless belts to ensure the formation of dense and uniform bales.

Processing and Control Systems:

The machine is available with several feeding system options to suit various needs:

•

SuperFeed: A rotary feeding system that ensures a smooth flow of long crops.

•

CropCutter: Equipped with 15 knives for fine crop cutting, increasing bale density and silage quality.

•

Binding System: Primarily based on net wrapping using Duckbill technology, with EdgeWrap™ for enhanced bale protection.

•

Electronic Control: Managed via IntelliView color touchscreens, the machine supports ISOBUS for direct connection to the tractor screen, as well as Tractor-Baler Automation, which automates stopping, binding, and unloading operations.

Innovation and Durability:

•

Newer models (such as the PLUS series) feature enhanced durability thanks to the use of 3.5 times thicker steel in the pulleys, heavy-duty chains, and triple-sealed bearings for dust protection. Optional technologies include real-time humidity sensors and surveillance cameras.

Specification

Demand for power take-off. min.

60 kW

Bale-Ø from-to

0.9-1.8 m

Bale width from-to

1.2 m

Standard tyres

500/55-20 150/A8

Pick-up width

 2.3 m

Weight

3.815 t

Number of axles

1

Transport length

4.815 m

Transport width

2.85 m

Transport height

2.985 m
